Construction
5 to 7 layer co-extruded composite material made from UV & FR reinforced PP non woven fabric with both side special highly reflective metalized film.
Typical Physical Property
| Property(Grammage) | Test Method(ISO 536) | Unit(g/sqm) | Results(125–140 (+/-5%)) |
| Tensile–MD and CD | ASTM D828 | N/25 mm | 100-200 |
| Burst Strength | ASTM D 774 | N/25 mm | 150 |
| Water Vapour Transmission | ASTM F 1249 | N | <1 |
| Temperature resistance | ASTM C 1263 –29 ˜66 ´C | - | Remains Flexible No Delamination |
| Reflectivity | ASTM E408 | % | 97% |
| Emissivity | ASTM E408 | % | 0.03 |
| Working Tempreture | - | Celsius | -50 to 110’C |
Nonwoven fabric which is a fabric-like material made from long fibers, bonded together by chemical, mechanical, heat or solvent treatment as backing, reflective aluminum foil as the outer surface laminated together by LDPE / acrylic adhesive, this foil insulation radiant barrier is light weight, environment friendly, soft and easy to fold; usually be installed in dry environment to prevent heat conduction and thermal radiant.
It is light in weight, excellent tear-resistance & good puncture resistance & excellent water vapor resistance and higher tensile strength. It is easy to handle during construction. Anti-aging, peel strength, and printable
Insulation Usage
Our Minaxi™ METNWMET It is used widely to make car cap to Reflective Sunshine & in Roof, floor, wall, pack food for heat Retaining, medical & sanitary, poultry industry & agriculture, construction & daily-used products such as the agricultural plant covers, roof waterproof material, disposable items for medical and industrial applications, liners for furniture, packing material, shopping bags, suit and garment cover, industrial protective coveralls, garment accessory materials, bed articles,
Medical and sanitary articles as well as family and hotel consume articles, especially for heat insulation, thermal insulation and construction and other fields.
Our Packaging Usage
Metalized film / Al Foil Laminated non woven fabric used in flexible packaging, waterproof material, decorative material, foodstuff packaging, barrier material, Low heat shrinkage area, high tensile strength requirement.Aluminum coating is well-proportioned has very high lusted degree, light reflectivity reach 98%,Suitable for yarn, cling packaging, cosmetic packaging and tobacco and liquor packaging.
Remarks
- Above data are typical results and not the guaranteed performance.
- Tolerance: Weight and Thickness: ±10%; Width: ±2mm; Length: ±0.5%.
- The products should be stored at room temperature away from wet and heat source.
- Please do trial-application and make sure the product can serve the specific application before actually put it to use.
Packaging Details
- Core ID: 76mm (3inch) Standard
- length: 250 mtrs, Other lengths available On request
- Thickness tolerance: +/-7% Maximum
- Width upto 1520mm
